This semi-automatic machine inserts seals and crimps terminals for two-core cables, fully servo-driven with industrial PC control and MES connectivity. Equipped with CCD vision inspection, real-time crimp force monitoring and pull testing, it serves automotive wiring harness and electronic cable production.
|
Model:
|
|
|
Brand:
|
|
○ Industrial PC with MES connection, real-time data upload, blade lifespan record & expiration alarm
○ 2T servo crimping, touchscreen mold adjustment, electronic parameter storage & one-click recall
○ Servo ball screw traverse for precise positioning and long service life
○ Seal-first stripping & crimping process to avoid copper wire reverse defects
○ Quick waterproof seal switching by replacing track hopper, inserts and guide clamps
○ Compatible with Japanese cassette molds, fast terminal change via mold replacement
○ CCD vision inspection for stripping length, wire & terminal appearance
○ Japan SOKU CFM pressure monitor for stable crimping quality
○ Pull-back test system with adjustable pull force via pressure regulating valve
|
Model |
YH-FSCJK02 |
|
Power Supply |
AC220V/50-60Hz |
|
Power Rating |
3500W |
|
Cycle Time (CT) |
≤6 s/sec |
|
Air Source |
0.5-0.7MPa (Dry & Clean) |
|
Wire Stripping Length |
1~10mm |
|
Sheath Stripping Length |
≥35mm |
|
Crimping Capacity |
2T |
|
Crimping Stroke |
30mm |
|
Equipment Weight |
Approx. 800KG |
