Our five-station wire harness tape wrapping machine is designed to streamline and enhance the wire harnessing process in various industries. This advanced machine is equipped with five stations, allowing for efficient and precise tape wrapping of wire harnesses.
|
Model:
|
|
|
Brand:
|
|
○ Multi-station functionality: With five stations, this machine can handle multiple wire harnesses simultaneously, increasing productivity and reducing production time.
○ Precision tape wrapping: The machine is designed to apply tape to wire harnesses with accuracy and consistency, ensuring a neat and secure finish.
○ Adjustable settings: Users can easily adjust the tension and speed of the tape wrapping process to suit different wire harness sizes and materials.
○ Durable construction: Built with high-quality materials, this machine is sturdy and reliable for long-term use in industrial settings.
○ User-friendly interface: The machine features an intuitive control panel for easy operation, making it accessible for operators of all skill levels.
| Model | YH-5D305 |
|
Working Environment |
0 - 40°C (Ambient Temperature) |
|
Suitable Air Pressure |
0.4 MPa - 0.6 MPa |
|
Equipment Dimensions |
L 1050mm × W 550mm × H 540mm |
|
Equipment Weight |
95 Kg |
|
Power Supply |
Two - phase, AC220V, 50HZ |
|
Equipment Power |
400 W |
|
Corresponding Workpiece |
Single or multiple wires with 5 points for simultaneous tape wrapping |
|
Working Efficiency |
5s |
|
Tape Material |
PVC, Masking Tape, etc. |
|
Wrapping Position Accuracy |
Within ±2 |
|
Wrapping Overlap |
Within ±2 |
|
Workpiece Length Range |
Maximum distance between the farthest wraps ≤ 620mm |
|
Workpiece Diameter Range |
3mm ≤ Diameter of workpiece to be processed ≤ 6mm |
|
Tape Width Range |
Tape Width ≤ 20mm |
|
Cutting Length Range |
20mm ≤ Tape Cutting Length ≤ 40mm |
|
Distance from End Position |
Distance between the tape edge and the extreme end of the workpiece ≥ 24mm, minimum interval ≥ 80mm |
