Fully Automatic Wire Cutting and Stripping Machine
Fully Automatic Wire Cutting and Stripping Machine
Fully Automatic Wire Cutting and Stripping Machine

Fully Automatic Wire Cutting and Stripping MachineFully Automatic Wire Cutting and Stripping Machine

Introducing our fully automatic wire cutting and stripping machine, designed to streamline your wire processing operations with utmost precision and efficiency. This machine is engineered to meet the demands of professional wire processing tasks, offering unparalleled performance and reliability.

Model:
  • YH-605
Brand:
  • Yuanhan
Inquire
Share to:
Features
Specifications

○ Function: cable cutting, outer jacket stripping
○ Optional: MES system, Internet of Things system, fixed-point coding function, middle stripping function, external auxiliary equipment alarm;
○ User-friendly system with intuitive operation via 7” color touchscreen;
○ Modular interface, easy to link accessories and peripheral equipment;
○ Modular design, can be upgraded in the future;
○ Various accessory options to customize the system. Special cable processing, non-standard customization.

Model

YH-605

Display method

7-inch human-machine interface

Function

Single-core wire, multi-core cable, shielded cable, fully automatic fixed-length cutting and stripping

Wire type

Single core wire, multi-core cable, shielded cable, PVC wire, etc.

Processing range

0.75 - 50 mm²

Cut off length

1mm-999999.99mm

Minimum total stripping length

Total length--Front end stripping length--Rear end stripping length>120mm

Cutting tolerance

Within 0.002*L (L=cutting length)

Stripping length

Front end full stripping: 1-200mm, front end semi stripping: 1-1500mm

Rear end full stripping: 1-100mm, rear end semi stripping: 1-300mm

The maximum diameter allowed to pass

Φ20

Tool material

High quality imported high speed steel

Productivity (times/hour)

3500 PCS/hour (depending on the length and size of the wire)

Drive mode

16-wheel drive (feeding stepper motor, tool holder servo motor); Roptional servo feeding

Wire delivery method

Belt feeding, no embossing or scratches on the cable. (With peeling and pressing function)

Lifting operation mode

Digitally adjustable pressure wheel height

Power supply

AC220V 50/60Hz; Roptional 110V 50/60Hz

Air source

0.5Mpa clean air source

Dimensions (length*width*height)

680*480*550mm

Net weight

95kg
