6-120 mm² Wire Cutting and Stripping Machine
6-120 mm² Wire Cutting and Stripping Machine
6-120 mm² Wire Cutting and Stripping Machine
6-120 mm² Wire Cutting and Stripping Machine
6-120 mm² Wire Cutting and Stripping Machine
6-120 mm² Wire Cutting and Stripping Machine
6-120 mm² Wire Cutting and Stripping Machine

6-120 mm² Wire Cutting and Stripping Machine6-120 mm² Wire Cutting and Stripping Machine

Whether you are in the automotive, aerospace, or electronics industry, our 6-120 mm² wire cutting and stripping machine is the perfect solution for your wire processing needs. Experience unmatched precision, reliability, and efficiency with this professional-grade equipment. Invest in our cutting-edge technology and elevate your wire cutting and stripping operations to new heights.

Model:
  • YH-612
Brand:
  • Yuanhan
Inquire
Share to:
Features
Specifications

○ With a wide range of features, our 6-120 mm² wire cutting and stripping machine offers unparalleled performance. Its robust construction ensures durability and longevity, making it a reliable choice for heavy-duty applications. The machine's cutting-edge technology enables it to handle wires ranging from 6 to 120 mm² with utmost precision.
○ Equipped with advanced controls, this machine allows for easy customization of cutting and stripping parameters, ensuring optimal results for various wire sizes and insulation types. The intuitive interface provides a user-friendly experience, making operation seamless and efficient.
○ Safety is paramount, and our wire cutting and stripping machine prioritizes it. It incorporates multiple safety mechanisms, including emergency stop buttons and protective covers, to prevent accidents and protect operators.
○ Efficiency is at the core of our machine's design. Its high-speed cutting and stripping capabilities significantly reduce production time, increasing overall productivity. Additionally, the machine's automatic wire feeding system minimizes manual intervention, further streamlining the workflow.
○ Maintenance is hassle-free with our 6-120 mm² wire cutting and stripping machine. Its modular design allows for easy access to components, simplifying routine maintenance and reducing downtime.
○ In addition to its remarkable functionality, this machine is built to withstand rigorous usage in demanding industrial environments. Its sturdy construction and top-quality materials ensure long-lasting performance, making it a reliable investment for your business.
○ Optional: MES system, Internet of Things system, fixed-point coding function, middle stripping function, external auxiliary equipment alarm.

Model

YH-612

Display method

7-inch human-machine interface

Function

fixed-length cutting and stripping

Wire type

single core wires, multi-core cables, shielded cables, etc.

Processing range

6-120mm²

Cutting length

1mm-999999.99mm

Cutting tolerance

Within 0.002*L (L=cutting length)

Minimum total stripping length total length--side A stripping length--side B stripping length >120mm

Stripping length

side A full stripping: 1 - 300mm; side A half stripping: 1-1000mm
side B full stripping: 1- 150mm; side B half stripping: 1-500mm

Max. diameter of guiding pipe

Φ30

Wheel lifting method

Stepper motor lifting wheel

Tool material

High quality imported high speed steel

Productivity

2000PCS/hour (depending on the length and size of the cable)

Drive mode

32-wheel drive (feeding stepper motor, tool holder servo motor); servo feeding optional

Wire delivery method

Belt feeding, no embossing or scratches on the cable. (With peeling and pressing function)

Lifting operation mode

Digitally adjustable pressure wheel height

Power supply

AC220V 50/60Hz; 110V 50/60Hz optional

Air source

0.5-0.8Mpa clean air source

Dimensions (length*width*height)

1200*720*1460mm

Net weight

270KG
