Rotary Multi-core Wire Cutting and Stripping MachineRotary Multi-core Wire Cutting and Stripping Machine

Our rotary multi-core cable cutting and stripping machine is designed to streamline the process of cutting and stripping both outer jacket and inner core insulation of multi-core cables. This advanced machine is equipped with cutting-edge technology to ensure precise and efficient operation.

Model:
  • YH-612XH
Brand:
  • Yuanhan
Share to:
Features
Specifications

○ With the ability to handle multiple cores simultaneously, our rotary multi-core cable cutting and stripping machine is perfect for high-volume production environments. The machine is capable of cutting cables to the desired length and stripping both the outer jacket and inner core insulation with precision and consistency.

○ Our machine is designed with user-friendly controls and adjustable settings to accommodate a wide range of cable sizes and types. The rotary cutting mechanism ensures clean and accurate cuts, while the stripping function removes insulation without damaging the core.

○ In addition, our rotary multi-core cable cutting and stripping machine is built with durability and reliability in mind, ensuring long-lasting performance and minimal downtime. This machine is a valuable asset for any manufacturing or assembly operation that requires efficient cable processing.

Model

YH-612XH

Display method

7-inch human-machine interface

Function

cutting and stripping both outer jacket and inner core insulation of multi-core cables

Processing range

6-120mm²

Cutting length

1mm-999999.99mm

Cutting tolerance

Within 0.002*L (L=cutting length)

Stripping length

side A full stripping: 1 - 300mm; side A half stripping: 1-1000mm
side B full stripping: 1- 150mm; side B half stripping: 1-500mm

Max. diameter of guiding pipe

Φ24

Wheel lifting method

Stepper motor lifting wheel

Tool material

High quality imported high speed steel

Productivity

800-1000pcs/hour (depending on the length and size of the cable)

Drive mode

24-wheel drive (feeding stepper motor, tool holder servo motor); servo feeding optional

Wire delivery method

Belt feeding, no embossing or scratches on the cable. (With peeling and pressing function)

Lifting operation mode

Digitally adjustable pressure wheel height

Power supply

AC220V 50/60Hz; 110V 50/60Hz optional

Air source

0.5-0.8Mpa clean air source

Dimensions (length*width*height)

1400*720*1460mm

Net weight

300KG

×
