Electric Busbar Peeling Machine

This machine is designed to streamline and enhance your busbar peeling process. Crafted with precision and engineered to perfection, our electric busbar peeling machine offers unrivaled efficiency and accuracy. It effortlessly removes the insulation layer from busbars, ensuring a clean and smooth surface for optimal conductivity.

Model:	YH-BTP220SK
Brand:	Yuanhan

Inquire

Share to:

Features

Specifications

○ The touch screen facilitates setting of cutting depth, cutting width, stripping length, positioning points, and common data storage (100 groups)

○ Special-shaped products (such as T-shaped) can be set to only cut without stripping. 2 cutting points can be set to automatically adjust the fixed points of each process.

○ The machine is equipped with a stripping waste collection device to facilitate the cleaning of the work surface.

Model	YH-BTP220SK
Stripping distance	2-150MM, only pressing but not pulling can be applied to products with a position of 200MM
Maximum specification of copper busbar	8MM * 50MM (thickness*width)
Minimum specification of copper busbar	1MM * 10MM (thickness*width)
Dimensions	1106558 CM
Voltage	AC220V
