2 Heads Crimping and Housing Connector Assembly Machine2 Heads Crimping and Housing Connector Assembly Machine

This is a fully automatic cable double-end housing shell inserting machine. It is able to process of double-end cutting, stripping, terminal crimping and housing connector inserting.

Model:
  • YH-STCJK03
Brand:
  • Yuanhan
Share to:
Features
Technical Data

○ Function: cable double-end cutting, stripping, terminal crimping and housing connector inserting
○ Independent double-knife seat, convenient and quick adjustment of the stripping depth
○ The insertion adopts 3-axis split operation, which effectively improves the insertion efficiency
○ Guided insertion method, effectively improving the insertion accuracy and protecting the functional area of the terminal
○ Flip-type defective product isolation method, 100% isolation of defective production

Model YH-STCJK03
Power supply AC 220v
Maximum power 4.8KW
Air pressure 0.4~0.6 MPa
Weight 800KG
Dimensions 2400L*1500W*1850H (excluding wire feeder and vibrating plate part)
Function

A end: stripping, crimping, housing insertion
B end: stripping, crimping, housing insertion

Processing range AWG20-AWG30
Processing length 950≥L≥80mm
Cutting precision 0.5mm+ cutting length*0.2%
Stripping length A end: 0.1-6.0mm (insertion end),B end:0.1-10.0mm
Crimping capacity 1.5KN
Maximum number of PINs 20 holes in a single row, up to 3 rows
Maximum PIN color number 8 colors (more colors must be customized)
Housing shell size MAX:40*25*25 MIN:5*6*3
×
