The fully automatic laser stripping, wire cutting and tinning machine uses CO₂ laser to cut the outer layer of the wire, and has unique advantages in processing high-end wires. Since CO₂ laser cutting only works on plastics and not on conductors, it has unique advantages. Using CO₂ laser to cut the outer layer of the wire, the incision is neat and the conductor is not damaged. It has high efficiency, high output, very low defective rate and is easy to operate. Therefore, the fully automatic laser stripping, wire cutting and tinning machine has become the first choice for cutting high-end wires.
|
Model:
|
|
|
Brand:
|
|
○ High quality, low defect rate during production
○ High output, effectively reducing production costs
○ High reliability, high stability
○ Customized according to customer needs, simple operation
○ A wide range of applicable materials: chlorides of ethylene polymers, glass fiber, polyester, polyester film, fluoride, nylon, polyethylene, silicone resin, other insulation layers of different hardness or high temperature, etc., suitable for most wires.
○ Laser stripping ensures that the wire conductor is not damaged. CO₂only works on the plastic coating of the wire and has no effect on copper metal. This solves the problem of stripping wires with high requirements, high difficulty and special requirements.
| Model | YH-JGZX01 |
| Motor | Mitsubishi + Inovance servo motor |
| Power | 2000W |
| Power supply | 220V/50HZ |
| Function | front and rear laser stripping, cutting, front and rear twisting, front and rear tinning |
| Cutting length | 20mm- 600mm |
| Cutting accuracy | 1mm±0.1mm |
| Stripping length | 0mm-15mm |
| Stripping tolerance | about±0.1mm |
| Feed quantity | 1-8PCS at the same time |
| Defective rate | less than 0.1% |
| Wire type | silver-plated wire, aircraft wire, military wire and other special wires |
| Laser type | Dawei 30W, CO₂ laser/air cooling |
| Laser frequency | 1KHz-25KHz |
| Laser wavelength | 10.6um |
| Cutting accuracy | ±0.1mm |
| Cutting speed | 0-500mm/S |
| Power requirement | AC220V±10% 16A |
| Supported graphic formats | DST, PLT, AI, BMP, DXF, JPG |
| Supported software | CORELDRAW PHOTOSHOP AUTOCAD AI |
| Applicable materials | FF soft cable, Teflon cable, aluminum foil Mylar ultra-fine coaxial cable, etc. |
| Usage environment | clean and dust-free, no vibration source |
| Air pressure | 5Mpa-7Mpa |
| Control mode | inch, single action and automatic (continuous) |
| Vulnerable objects | blades |
| Accessories | 2 sets of blades, 1 set of tools, 1 manual |
| Appearance size | 3000mm*1200mm*1950mm |
| Weight | 780Kg |
