Introducing our fully automatic cable single end housing connector assembly machine, designed to streamline and optimize your production process. This machine is equipped with advanced technology to efficiently cut, strip, and assemble housing connectors with precision and accuracy.
|
Model:
|
|
|
Brand:
|
|
○ With the ability to handle a wide range of cable sizes and connector types, this machine is versatile and adaptable to meet your specific needs. The fully automatic operation ensures consistent and reliable results, saving you time and labor costs.
○ Our machine is built to the highest standards of quality and durability, ensuring long-lasting performance and minimal maintenance requirements. The user-friendly interface allows for easy operation and monitoring of the assembly process.
| Model | YH-YJCJK01 |
| Main Functions |
Fix Length Wire Cutting Auto Stripping and Twisting Single-End Terminal Crimping and Housing Insertion Auto Sorting for OK/NG Product Auto Wire Quantity Sorting |
| Fault Detection |
Wire Missing Warning Tin Missing Warning Abnormal Air Pressure Warning Visual Inspection with Charge Couple Device(CCD) Crimping Pressure Sensor(Optional) |
| Wire Length Range | 25-1000 mm (Consult manufacturer for special length requirement) |
| Productivity |
8000-12000 Pin/Hour (Varies according to the type of terminal, plastic housing and wire used) |
| Processable Wire Range | AWG18-AWG30(Varies according to the type of wire material) |
| Plastic Housing Range |
Pin Intervals 1.0-3.96 mm Pin Numbers 1-20Pin |
| Stripping Length Range |
A End 1~7 mm; B End 1~12 mm (Customize for special specifications) |
| Power Supply | 50/60Hz，220V Single Phase AC |
| Air Pressure | 0.5~0.7 MPa (clean and dry air source is required) |
| Crimping Capacity | 2.0T Ultra Quiet Precision Terminal Crimping Machine |
| Dimensions | L 2200mm x W 1120mm x H 1600mm |
