Parallel Twin Cable Splitting and Stripping Machine

Parallel Twin Cable Splitting and Stripping Machine

This is a fully automatic flat cables cutting slitting and stripping machine. It is able to process of twin flat cables/parallel flat cables and multi-pin flat cables.

Model:	YH-BXFX01
Brand:	Yuanhan

Inquire

Share to:

Features

Specifications

○ Function: flat cable cutting, slitting and insulation stripping
○ Automatic cable feeding, output setting, timing start
○ Cutting length: 1-99,999.9mm
○ Slitting length: 0.1-150mm
○ Stripping length: head stripping: 25mm, tail stripping: 80mm

Model	YH-BXFX01
Cutting length	1-99,999.9mm
Stripping length	head stripping: 25mm, tail stripping: 80mm
Middle stripping	15 sections
Slitting length	0.1-150mm
Core wire cutting	0.1-10mm2
Cutting tolerance	0.002*L mm
Catheter size	3*20mm
Blade material	imported high-speed steel
Drive mode	4-wheel drive
Cable pressure adjustment	Yes
Pulse equivalent	no error within 5mm
Drive motor	stepper motor 0.1mm
Number of slitting	2-12 pins
Effective efficiency	3,000-8,000pcs/h
Dimensions	400300330mm
Weight	40KG
