Our multiple wire twisting and heat shrink tube inserting machine is a versatile and efficient tool designed for crimping terminals at the tails of two to six wires, twisting the wires together, and inserting heat shrink tubing.
|
Model:
|
|
|
Brand:
|
|
○ This machine is equipped with advanced technology to ensure precise and consistent results with every use. It is suitable for a wide range of applications in various industries, including automotive, electronics, and telecommunications.
○ The crimping function of this machine ensures secure connections between wires, while the twisting feature helps to streamline the wiring process and reduce the risk of tangling. The heat shrink tube inserting capability adds an extra layer of protection to the wires, safeguarding them against environmental factors and wear and tear.
○ With user-friendly controls and a durable construction, our multiple wire twisting and heat shrink tube inserting machine is built to withstand heavy-duty use in industrial settings. It is easy to operate and maintain, making it a valuable addition to any production line.
| Model | YH-DXNXTGJ |
| Processing wire | #22-#14 AWG |
| Processing capacity | Wire length 80-150mm, two wires about 1500 wires/hour, six wires about 800 wires/hour. |
| Cutting accuracy | Wire length below 100mm, error 0.2+(wire length x 0.002) |
| Wire length above 100mm | error 0.5+(wire length x 0.002) |
| Processing length | 76mm~99999mm with rubber in the middle |
| Stripping length | 0.5~8.0mm at the front, 0.1~10.0mm at the back |
| Cutter depth | Maximum adjustment 5.50mm, resolution 0.01mm |
| Detection device | Low air pressure, presence of wire, abnormal crimping, abnormal wire entry |
| Power supply | Single phase AC200V~242V 50/60Hz 10A |
| Compressed air | 0.5 MPa(5kgf/cm2), clean and dry gas |
| Dimensions | W 800 *D1800*H1800 mm |
| Weight | about 700KG |
