Ultrasonic Wire to Connector Splicer MachineUltrasonic Wire to Connector Splicer Machine

Introducing our ultrasonic wire to connector splicer machine, a cutting-edge solution for seamlessly joining wires to connectors with precision and efficiency. This machine is designed to meet the demands of various industries requiring reliable and high-quality wire splicing.

Model:
  • YH-N2060
Brand:
  • Yuanhan
Share to:
Features
Specifications

○ Digital circuit, adjustable amplitude

○ Automatic frequency tracking (truly fully automatic frequency tracking, no need to adjust frequency when changing heads)

○ Dynamic indication of welding current, use time, power, amplitude and other parameters are displayed

○ Frequency and overcurrent protection can be manually adjusted during welding

○ Precision linear guides can ensure smooth operation of the equipment and optimal welding accuracy

○ The power box maintains stable output when the voltage fluctuates

○ Advantages: short welding time, high efficiency, fast welding time, energy saving. Good conductivity and high strength after welding,

○ Resistance is zero. No need to add any solder. No sparks, no smoke, safe.

Model YH-N2060
Input voltage 220V
Maximum output power 6000W
Working frequency 20KHZ
Welding time 0.5S-2S
Welding area < 50mm²
Operating humidity 0-40°
Working air pressure 0.2-0.8MPa
Ambient temperature 20-70
Bracket dimensions 46x15x14cm
Electric box dimensions 58x18x46cm
Machine weight 80KG



×
