This semi-automatic wiring harness taping machine is mainly used for wrapping tapes onto wire harness used in automobiles, motorcycles and aviation industries, playing the role of marking, fixing and insulating. It is suitable for continuous taping, spot taping, and spiral taping. This intelligent automatic tape wrapping machine provides automation for the molding, placement and winding of complex wire bundles and improves production efficiency.
Model: AT-3608
Features
○ Compatible with different types of tape materials without release paper, such as cloth tape, PVC tape, etc.
○ Working mode: full winding, spot winding, multi-section winding
○ Tape width:The normal tape width is 19MM, and the set tape width directly affects the winding density.
○ The smaller the set width of the tape, the larger the overlap surface. The larger the set width of the tape, the smaller the overlap surface.
○ Running speed:The highest speed is 80, the lowest speed is 10
Contact us: sales@yuanhanequip.com
Operation video of the spiral taping machine for wiring harness
Technical Data
Model | AT-3608 | AT-3608 Plus |
Available Wire Harness Dia. | φ3-30mm | φ3-40mm |
Tape Width | 2-30mm | 2-30mm |
Wrapping Length | No limitation | No limitation |
Power Supply | 110/220VAC, 50/60Hz | 110/220VAC, 50/60Hz |
Dimension | 65*52*40cm | 62*61*55cm |
Weight | 48kg | 72kg |
Note | Can be customized according to customer requests. |
