TYGON Tubing Cutting Machine, PVC Plastic Tubing Cutting Machine

Views: 642 Author: Site Editor Publish Time: Origin: Site

A versatile and reliable machine for cutting to length of TYGON tubing, PVC plastic tubing, heat shrink tubes, fiberglass tubes, teflon tubes, silicone tubes, yellow wax tubes, PVC tubes, PE tubes, plastic tubes, rubber hoses, wire ropes and non-adhesive strip materials like belt loop, string, plastic zipper, elastic band, small webbing, etc.

Model: ZCUT-100S

TYGON Tubing Cutting Machine, PVC Plastic Tubing Cutting Machine

Features

  • High efficiency and high accuracy: up to 120-150 times per minute;

  • Tolerance: +/- 0.5% of cutting length;

  • Cutting type: Cold cutting with a durable cold knife;

  • Suitable for cutting fiberglass tubes, teflon tubes, silicone tubes, yellow wax tubes, PVC tubes, PE tubes, plastic tubes, rubber hoses, wire ropes, electric cables, and non-adhesive strip materials like belt loop, string, plastic zipper, elastic band, small webbing, insulation paper, copper foil, copper sheet, nickel tape, cotton tape, etc.

  • Automatic operation: It works automatically only by setting length and quantity;

  • Automatic stopper: It stops automatically if materials run out during operation;

  • Memory function: the previously set length, quantity and speed will not be erased even if power off & on;

  • We supply different models to fit your requests.

Contact us: sales@yuanhanequip.com


Operation video of the TYGON Tubing Cutting Machine


Technical Data

Model   ZCUT-100S
Cutting length (mm) 1mm-99999mm
Cutting accuracy (mm) 0.1mm
Max Hose Dia. (mm)  25mm
Cutting speed(p/min) 150
Knife type cold knife
Voltage/ frequency(V/Hz)  110V/220V 50Hz/60Hz
Rating Power 500W
Dimension (mm) 430×300×480(LxWxH)
Weight 30kg


×
