Cable Shield Brushing and Wire Twisting Machine

Cable shield braid brushing and twisting machine is mainly used for brushing the outside braid of shielded cable. It can brush and twist cable braid layer all-in-one. The speed is controllable, and the performance is stable. It is a common and necessary equipment for wire harness processing. The machine can be used for processing different kinds of ground cables, braided cables, shielded cables, etc.

Model:
  • YH-NXJ
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Beatiful shape, small size, portable

  • Pure copper silent high-speed motor to ensures stable machine performance and its long life-span

  • Elastic clamp in this machine is suitable for different wire sizes and need not adjust machine manually, saving a lot of time

  • Automatic wire pulling, easy to operate, smooth twisting, more stable quality

  • Exposed design for automatic clamp is easy to collect loose copper wires together

Model
YH-NXJ
Working voltageAC220v/50hz
Working pressure4-6kg/cm
Motor power10W
Twist wire diameter1-8mm
Twist wire length5-60mm
Weight10KG
Dimension340*190*170mm


×
