Kunshan Yuanhan Electronic Equipment Co., Ltd.

Ultrasonic High Speed Webbing Tape Cutting Machine

The high speed ultrasonic webbing tape cutting machine is able to cut different kinds of webbing and ribbons, such as labels, elastic bands, narrow woven fabrics, belts, straps and much more. The cutting edge is neat and smooth, no burrs, no loose edges.

Model:
  • YH-D310
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Automatic sealing, neat and smooth cutting edge, no burrs, no loose edges.

  • PLC control, feeding, cutting, and counting can be completed at one time.

  • Cutting material: webbing tape, elastic belts, nylon webbing, colored ribbons, backpack belts, shoe laces and other nylon materials.

  • Adopt high-quality ultrasonic generator and control system.

  • Support cutting different shapes, and the mold is easy to change.

  • Electronic eye is optional to track cutting labels and patterned materials.


ModelYH-D310
Efficiency100-500pcs/min
Ultrasonic frequency18 khz
Power220v, 1.8kw
Weight100kg
Packing size610*610*960 (L*W*H) mm



×
