Automatic Hot & Cold Knife Woven Belt Cutter Machine Standard Model

Automatic Hot & Cold Knife Woven Belt Cutter Machine Standard Model

This automatic hot-cold knife cutting machine is suitable for cutting woven belt, nylon buckles, lining, fabric tape without heat seal, plastic zipper, metal zipper, plastic lace, PVC tube, leather, aluminum platinum, PS material and so on.

Model:	ZCUT-120LH Standard
Brand:	Yuanhan

Inquire

Share to:

Features

Specifications

Easy Operation: it can cut automatically once set up the cutting length and quantity.
Self-protection Function: It will stop automatically if the materials run out during the operation.
High Speed: It can cut 100-120pcs per minute(50mm length for example)
High Accuracy: using stepping motor, the cutting length is accurate
Application: woven belt, nylon buckles, lining, fabric tape without heat seal, plastic zipper, metal zipper, plastic lace, PVC tube, leather, aluminum platinum, PS material and so on.
We offer a variety of special blades so you can get different shapes of cutting edges.

Model	Cut length (mm)	Max cut width (mm)	Cut Speed (P/min)	Weight (Kg)	Voltage /frequency (V/Hz)	Rating power (KW )	Knife max temperature(°C)	Packing size (mm)
ZCUT-120LH	1-99999	100	100-120	26	110V/220V50/60	0.5	350	450350350
ZCUT-101	1-9999	1-105	100-120	21	220V	0.4	cold	500350350
ZCUT-102	1-9999	100	100-120	26	110V/220V50/60	0.5	350	450350350
ZCUT-102A	1-9999	100	100-120	26	110V/220V50/60	0.5	cold	450350350
ZCUT-130	1-99999	95	100-120	26	110V/220V50/60	0.5	250	500350350
ZCUT-150	1-99999	105	100-120	21	220V	0.4	cold	500350350
