Kunshan Yuanhan Electronic Equipment Co., Ltd.

Double Head Elastic Staple Fastening Machine

The double-head plastic staple fastening machine can complete two binding positions at one time, which can double the efficiency, especially suitable for fast fastening hardware and kitchen utensils.

Model:
  • YH-11803
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • The elastic staple system is used to replace the traditional packaging methods such as cable ties, paper ropes and iron wires, which can increase your packaging speed and production

  • Adjustable needle pitch range: 10-80MM

  • 2.6mm wide elastic staple

  • The stability and efficiency of this elastic staple fastener machine benefit from the smooth 3D dynamic modeling design and the precision machining of internal movement parts.

  • Our elastic staples are made of imported special polyurethane materials, which are safe and environmentally friendly and naturally degradable.

  • The double-head plastic staple fastening machine can complete two binding positions at one time, which can double the efficiency, especially suitable for fast fastening hardware and kitchen utensils.

ModelYH-11803
Adjustable needle pitch range10 MM-80 MM
Drive modePneumatic pedal plate
Standard needle length80 MM
Standard length of thimble145 MM
The blade configurationLeft/right universal blade
Effective needle length space100 MM
Needle diameter2.3 MM
The host weight3.8 KG * 2 sets
Total weight28.5 KG
Dimensions(CM)Customized baseplate according to customer's products
Aluminum frame80*80 strengthen aluminum frame
Working tableCan be customized
Integral parts processing methodPrecision machining
Machine configurationMain engine head, aluminum frame, black lacquer worktable, reel bracket


×
