Kunshan Yuanhan Electronic Equipment Co., Ltd.
This high speed ultrasonic woven tape cutting machine is suitable for cutting and punching all kinds of washing water mark, sticker trademark, woven label, printed label, ribbon, non-woven fabrics, PVC trademark, etc. Featuring high speed and accurate feeding motor, the speed can reach 150 times / min, and the accuracy can reach 0. 3mm at a cutting length of 2.5m.
Model:
|
|
Brand:
|
|
Suitable for cutting all kinds of washing water mark, sticker trademark, woven label, printed label, ribbon, non-woven fabrics, PVC trademark, etc.
Ultrasonic cutting, the cut is smooth and flat, absolutely not scattered
Equipped with SUNX photoelectric eye from Japan, featuring high precision and simple operation
Independently developed control system with reasonably clever structural design, speeds up to 150 times/min
It has the function of discharging waste, eliminating the influence of waste and making the machine work continuously
Adjustable cutter speed and feed speed, fully control the speed of the machine
High speed and accurate feeding motor, the accuracy can reach 0. 3mm at a cutting length of 2.5m
The control system has four working modes, including debug mode, positioning mode, fixed length mode and discharge mode. These working modes can meet different cutting requirements of various materials
Large LCD display in Chinese (English), simple and convenient
Model | ZCUT-803D |
Power | 220V / 50HZ |
Cutting length | 1mm-1000mm |
Cutting width | 0-100mm |
Weight | 103kg |
Tool material | high speed steel D2 |
Feeding speed | 150 times / min |
Dimensions | 800L x460w x1200H mm |
Power | 2200W |
Roller material | stainless steel |
Automatic feeding | Yes |
Discharge function | Yes |
Suitable materials | washing water mark, sticker trademark, woven label, printed label, ribbon, non-woven fabrics, PVC trademark, etc. |
