Visual Positioning Convoluted Tube Cutting Machine with Shrinking FunctionVisual Positioning Convoluted Tube Cutting Machine with Shrinking Function

This fully automatic visual positioning corrugated pipe cutting machine features simple operation, accurate positioning, high cutting precision and long service life. Cutting and tube shrinking can be done at one time. It can be used to cut various plastic pipes used in chemical, medical and other industries.

  • YH-BW10
  • Yuanhan
Share to:
  • Visual camera positioning: 1.3 million pixels

  • Simple operation, accurate positioning, high precision and long service life

  • Belt traction, no indentation

  • Automatic collection system, efficient and convenient

  • Cut plastic pipes used in chemical, medical and other industries

Positioning methodCamera positioning
Lens16/25mm lens
Camera pixels1.3 million pixels
Positioning accuracy±0.15mm
Cutting speedwithin 12m/min (cutting length≥500mm), which can be adjusted according to the extrusion line speed.
Cutting diameterOD 5mm-40mm
Number of cutting segmentsSixteen different lengths of cyclic cutting, must be the same from the recognition point to the cutting point at both ends
Feeding methodcrawler type
Camera field of view70mm
Cutting methodCylinder cutting
Cutting effectsmooth and free of burrs
Tube pressing methodMotor adjustment
Power supply220V50Hz
Air pressure0.6Mpa
Length of tube shrinking1600mm
Tube shrinking methodbelt reciprocating
Tube shrinking diameter25-40mm
DimensionsLength 1160xWidth 580xHeight 1500 (without protrusions)
