Electric Vertical Tensile Testing MachineElectric Vertical Tensile Testing Machine

This electric vertical tensile testing machine is suitable for processing of push-pull load test, plug-in force test, and destruction test. It is widely used in industries of rubber and plastics, light industrial textiles, building doors and windows, composite materials, wires and cables, auto parts, power machinery, scientific research institutions and other industries.

Model:
  • YH-AEV
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Double pole structure, easy to use, good stability and wide application range.

  • Electric loading, stepless speed regulation, gear transmission.

  • Compact structure and stable transmission.

  • The operation is simple and can be used in combination with various fixtures.

Model

AEV-5000

AEV-5000(higher type)

AEV-10000

AEV-20000

AEV-30000

Maximum load

5000N

10000N

20000N

30000N

Effective stroke 220mm(220mm-1000mm can be customized)
Test speed

60~220 mm/min

(The speed varies   according to the load, and the speed becomes slower when the load becomes heavier)

50~180mm/min

(The speed varies according to the load, and the speed will decrease when the load increases.)

Working voltage

AC 220V

Dimensions(mm) 400×250×1050 400×250×1300 430×250×1160

Net weight

56kg

60kg

65kg



×
