DC Cable Winding and Bundling MachineDC Cable Winding and Bundling Machine

The DC power cable coiling and bundling machine can complete coil winding and twisting tie at one time.

Model:
  • YH-680-DC
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Cable coil winding and bundling can be finished at one time

  • The length of the wire head, wire tail and wire coil can be adjusted

  • The whole machine is controlled by PLC and servo motor. The operation is simple, saving labor and increasing output.

ModelYH-680-DC
Capacity1,100-1,400PCS/H
Wire head size 0-100mm
Wire tail size30-400mm
Wire winding length120-220mm
Wire lengthMax. 4,000mm
Operating air pressure0.5-0.7Mpa
Power1.6kw/h
Machine weight220KG
Machine size1005mm*690mm*1560mm


×
