This hydraulic wire terminal crimping machine is able to crimp terminals to wires ranging from 1-120 square mm. It is suitable for B mouth and hexagon terminals crimping.
|
Model:
|
|
|
Brand:
|
|
○ Crimp terminals to wires ranging from 1-120 mm²
○ Suitable for B mouth and hexagon terminals crimping
○ Appearance: compact size, space-saving, suitable for workshop
○ Weight: 75kg, easy to move
○ Voice: low noise
○ Power Consumption: 0.75Kw/H, economic and energy-saving
○ Operation Method: jog up and down/semi-automatic/automatic
○ Application: 1-120 mm² , B mouth and hexagon terminal
○ Exuberant output, stroke adjustable, stable crimping
| Model | YH-40T |
| Output pressure | 40 Ton |
| Applicable cable size | 1-120mm² |
| Dimension | 600*280*600mm |
| Power supply | AC 220V/50Hz-60Hz |
| Stroke | 50mm (adjustable) |
| Control method | Hydraulic electric |
| Weight | 75KG |
