Fully Automatic Wire Cutting Stripping & 2-side Crimping MachineFully Automatic Wire Cutting Stripping & 2-side Crimping Machine

This is a fully automatic terminal crimping machine. It is able to process wire cutting, wire stripping, and single-side terminal crimping & 2-side terminal crimping.

Model:
  • YH-STJ02
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Machine function: wire cutting, wire stripping, single-end crimping, and double-end crimping

  • Wire range: AWG18#-28#

  • Suitable for OTP horizontal applicator and vertical applicator

ModelYH-STJ02
Machine functionwire cutting, stripping, single-end crimping, double-end crimping
Wire rangeAWG18#-28#
VoltageAC220W 50Hz
Rated power2.5KW
Working pressure0.4-0.6MPa (stable, clean, dry)
Cutting length40mm-9,900mm
Cutting tolerance≥1m, ±0.2%
Stripping length0.5mm-10mm
Cutting speed4,000 pcs/h (within 100mm)
Processing efficiency3,800 or more/h (within 100mm)
Crimping force2.0T (other crimping force can be customized)
ApplicatorOTP horizontal applicator and straight applicator
DimensionsL800xW700xH1,550
Weight330KG



×
