Semi-auto Wire Stripping Rubber Seals Inserting and Crimping MachineSemi-auto Wire Stripping Rubber Seals Inserting and Crimping Machine

This wire stripping & rubber seals inserting and crimping machine adopts a linear module to process wire rubber seals loading, wire stripping and crimping in an orderly combination, and each function can be used independently.

Model:
  • YH-F2000
Brand:
Share to:
Features
Specifications
  • Function: wire rubber seals loading, wire stripping and crimping. Each function can be used independently.

  • Saving labor and improving working efficiency

  • Stripping length can be adjusted digitally

  • Wire seals loading depth can be adjusted according to the data of the glue position between the stripping and the rubber seals

  • The depth of the crimping end rubber can also be adjusted according to the position of the top line.

  • The crimping machine adopts high efficiency servo motor drive, which can process high speed crimping with stable pressure

  • The stripping slide is driven by screw to ensure the peeling length is accurate

  • The cutting mechanism is driven by motor and screw, and the cutting depth can be adjusted digitally.

  • The seals feeding structure is simple and easy to replace, meeting the requirements of customers with various types of products.

  • The machine is easy to operate, stable in quality and concentrated in function.

Model
YH-F2000
Stripping length0-10.0mm
Applicable wire size0.2-2.5mm²
Suitable wire seals≤Dia.10×10
Cutting error
±0.02mm
Crimping capacity3T
Stroke40mm
Output
1000-1200 piece/H
CT
1 pcs / 3s
Air source0.5~0.7mpa
Power supply110/220VAC,50/60Hz
Weight300kg
Dimensions
85*88*130 cm


×
