Kunshan Yuanhan Electronic Equipment Co., Ltd.

Two-ends Terminal Pressing Tinning and Housing Inserting Machine

This fully automatic machine is able to process wire cutting, two ends stripping, crimping, tinning and housing inserting. Cutting length: 85-700mm; Stripping length: 0.5-10mm. Applicable wire sizes: 0.8-2.0mm (28#-20#).

Model:
  • YH-07D
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Wire cutting, two ends peeling, crimping, tinning and housing inserting

  • Cutting length: 85-700mm; Stripping length: 0.5-10mm

  • Applicable wire sizes: 0.8-2.0mm (28#-20#)

  • Equipped with detection device

ModelYH-07D
FunctionCutting/stripping/pressing/tinning/twisting/housing inserting
Productivity3800pcs/H
Wire Sizeoutside diameter: 0.8-2.0mm (28#-20#)
Cutting Length85-700mm
Stripping Length0.5-10mm
Pressure2T
Power SupplyAC220V 50/60Hz
Air Pressure0.5-0.7Mpa
Dimension1500L*1200W*1650H

Detector

1.Air pressure alarm

2.Defective product recognition

3.Terminal exist or not

4. Visual computer equipment


×
