The fully automatic British plugs production line integrates automatic traction of the entire axis, wire feeding, wire cutting, tail stripping, color discrimination, neat core wire, core stripping, color checking, riveting, polarity & exposed copper wire checking, and installing pressure cap together.
Model:
|
|
Brand:
|
|
○ The fully automatic British plugs production line integrates automatic traction of the entire axis, wire feeding, wire cutting, tail stripping, color discrimination, neat core wire, core stripping, color checking, riveting, polarity & exposed copper wire checking, and installing pressure cap together.
○ Applicable wires: H03VV-F, H05VV-F
Model | YH-880-Y |
Capacity | 1,000-1,200pcs/h |
Riveting force | 3T |
Yield | ≥99% |
Wire stripping size | 4-7mm |
Voltage | AC220V/50HZ |
Operating air pressure | 0.5-0.8MPa |
Power | 1.5kw |
Machine weight | 2500KG |
Dimensions | 3200mm*2500mm*1900mm |
