Kunshan Yuanhan Electronic Equipment Co., Ltd.

Fully Automatic French Electrical Plugs Production MachineFully Automatic French Electrical Plugs Production Machine

The fully automatic French plugs production line integrates automatic traction of the entire axis, wire feeding, wire cutting, tail stripping, color discrimination, neat core wire, core stripping, color checking, riveting, polarity & exposed copper wire checking, and installing pressure cap together.

Model:
  • YH-880-F
Brand:
  • Yuanhan
Share to:
Features
Specifications

○ The fully automatic French plugs production line integrates automatic traction of the entire axis, wire feeding, wire cutting, tail stripping, color discrimination, neat core wire, core stripping, color checking, riveting, polarity & exposed copper wire checking, and installing pressure cap together.

○ Applicable wires: H03VV-F、H05VV-F

Model YH-880-F
Capacity 1,000-1,200PCS/H
Riveting force 3T
Yield ≥99%
Core wire stripping size 4-7MM
Voltage AC220V/AC380V 50HZ
Operating air pressure 0.5-0.8MPa
Power 1.5KW
Machine weight 2500KG
Machine size 2,200MM*2,500MM*1,900MM





×
