This is a semi-automatic france standard power plug riveting machine. Applicable wires: H03VV-F, H05VV-F, H05RR-F, H07RN-F, H03V2V2-F, H05V2V2-F, and H05BQ-F.
Model:
|
|
Brand:
|
|
This machine integrates cable outer jacket stripping (cable head), powder sweeping, core wire color identification, wire splitting, core wire neating, trimming, core opening, polarity identification recheck and Bridge frame stamping together.
Applicable cable types: H03VV-F, H05VV-F, H05RR-F, H07RN-F, H03V2V2-F, H05V2V2-F, H05BQ-F (cotton yarn cable and rubber cable cannot be used).
The whole machine is controlled by PLC man-machine interface, and the operation is safe and fast.
Model | YH-880 |
Capacity | 1,000-1,200pcs/h |
Force | 3T |
Good product rate | ≥99% |
Stripping wire size | 4-8mm |
Voltage | AC220v / 50HZ |
Operating air pressure | 0.4-0.6MPa |
Power | 1.5KW |
Machine weight | 1,800KG |
Machine size | 2,500*2,500*1,900MM |
