Kunshan Yuanhan Electronic Equipment Co., Ltd.
This fully automatic coaxial wire stripping machine is designed for processing of coaxial cables used in the field of communication manufacturing. It can perfectly cut the woven mesh layer without injuring the inner layer. Wire cutting and multi-layer or multi-stage peeling can be done at one time. Processing cable diameter: 0.6-4.0 mm. Maximum stripping layers: 8 layers.
Model:
|
|
Brand:
|
|
This fully automatic coaxial wire stripping machine is designed for processing of coaxial cables used in the field of communication manufacturing
Wire cutting and multi-layer or multi-stage peeling can be done at one time
The coaxial wire stripping machine adopts rotating cutter head to rotate and cut, the V-shaped blade cuts and peels, and the two sets of cutter heads cooperate with each other to more accurately improve the quality and output of the processed products
It can perfectly cut the woven mesh layer without injuring the inner layer
Model | YH-9800 |
Processing cable diameter | 0.6-4.0mm |
Minimum processing diameter | 0.6mm |
Maximum skinning length | 20mm |
Cutting depth unit | 0.01mm |
Peeling precision | ±0.1mm |
Maximum stripping layers | Up to 8 layers (adjustable) |
Weight | 102KG |
Power supply | 110V /220V/50HZ |
Packaging size | 760*700*400mm |
