1-16mm2 Cable Cutting and Stripping Machine1-16mm2 Cable Cutting and Stripping Machine

This fully automatic wire cutting and stripping machine is able to remove outer insulation of cables. The applicable wire sizes range from 1-16 sq mm.

Model:
  • YH-8010
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Function: fully automatic wire cutting and stripping

  • Applicable wire sizes: 1-16 square mm

  • Strip outer sheath of single conductor cables

  • Drive mode: 16-wheel drive (silent hybrid stepper motor, servo tool holder)

  • Belt feeding wires, no embossing and scratches

ModelYH-8010
Display7-inch true color touch screen
Stripping range1-16 mm2
Cutting length1mm-99999.99mm
Cutting tolerancewithin 0.002*L (L=cutting length)
Stripping length

Side 1 full strip: 1-190mm, side 1 semi strip: 1-1500m

Side 2 full strip: 1-80mm, side 2 semi strip: 1-500mmm

Maximum diameterΦ10mm
Tool materialhigh-quality imported high-speed steel
Productivity3600 pcs/hour (depending on the length and size of the wire)
Drive mode16-wheel drive (silent hybrid stepping motor, servo tool post)
Wire feeding methodbelt feeding, no embossing and no scratches on the cable
×
