Inductive Electric Wire Stripping MachineInductive Electric Wire Stripping Machine

The YH-2017C is a pure electric wire stripping machine, which comes with multiple cable processing modes: half strip, full strip, double-layer strip and more. Processing range: AWG30-AWG4 (0.04-20 square mm).

Model:
  • YH-2017C
Brand:
  • Yuanhan
Share to:
Features
Specifications
  • Pure electric wire stripping machine, high precision, simple and convenient debugging

  • High accuracy, no need for foot switch

  • Multiple processing modes meet different types of wire processing. (half strip, full strip, double-layer strip, etc.)

  • It adopts a 90-degree V-shaped knife edge design, which has strong versatility and does not need to change the blade when processing different wires.

  • Both the gripper and the knife edge adopt the translation principle to ensure that the center height remains the same when processing different wire diameters

  • Up to 30 sets of processing parameters can be stored

  • Processing range: AWG30-AWG4 (0.04-20 square millimeters), stripping length 1mm-40mm

ModelYH-2017C
Processing rangeAWG30-AWG4 (0.04-20 square mm)
Functionhalf strip, full strip, double-layer strip, etc.
Production capacity1800-2000 pieces/hour (depending on operating proficiency)
Stripping length1mm-40mm
Adjustment accuracy0.05mm
Working voltageAC220V 50/60Hz
Dimensions500mm*620mm*300mm
Weight20kg



×
